| DISPLAY PROPERTIES |
Panel Size
|
65 inch |
| Resolution |
1920×1080 |
| Point Range |
0.744mm x 0.744mm |
| Angle of view |
Vertical 178° Horizontal 178º |
| Viewable area |
1428.48mm×803.52mm |
| Maximum Brightness |
360cd/m2 |
| Maximum Contrast |
4000;1 |
| Response Time |
8ms |
| Number of Colors |
1.07 Billion |
| Colour Swatch |
72% |
| SIZE |
TV Weight (Net, Gross) |
78kg - 88kg |
| TV Dimensions (Device - Packet) |
1610 x 965 x 140mm - 1810 x 1165 x 360mm |
| POWER |
Power Consumption |
≤300W |
| Standby Power Consumption |
≤2W |
| Operating Voltage Range |
100V-240VAC 60/50Hz |
| SOUND |
Maximum audio input power |
10W+10W |
| Maximum audio output power |
10W+10W |
| INTERFACES |
HDMI input |
2 |
| VGA input |
1 |
| S-VIDEO input |
1 |
| AV input |
4 |
| AV output |
1 |
| USB |
2 |
| Audio Input |
1 |
| Audio Output |
1 |
| DETAILS |
8 / 10b 2 LVDS (1920 * 1080) FHD support |
|
| PAL + NTSC and PAL + SECAM support |
|
| 3D Digital Comb Filter |
|
| True Color OSD, User-Friendly Menu |
|
| Nicam sound system for the analysis of different technologies, BTSC, A2, EIA-J, etc. |
| Automatically the color and appearance of mstara-5 engine,improving image contrast, image sharpness, color tone editing, etc. |
| Programmable 12-bit RGB Gamma Correction Technology |
|
Returning to setting option Fakrik |
|
| 2 * HDMI 1.3 inputs with HDCP 1.2 supported |
|
| Editing software to reduce EMI radiation frequency |
|
| 3D noise reduction technology |
|
| FHD and JPEG analysis technology |
|
| Digital Audio amplifier |
|
| Touch Screen Specifications |
touch Technology |
Optical Touch |
| The touch user objects |
Finger or Pen |
| Detection diameter |
Diameter>= 5 mm,recommended> = 7 mm |
| resolution |
32767 x 32767 |
| Response Time |
Single mode: first touch: 7ms touch continuity: 3ms |
| Multiple mode: first touch: 8ms, touch continuity: 8ms |
| Response Rate |
125Hz |
| Lifecycle |
50,000 hours |
| LCD panel protection |
5mm Tempered Glass |
| Touch Panel Power Supply |
USB or 5V DC Power Supply |
| Power Consumption |
<= 1W (700mA) |
| Operating System Support for Multi-Touch |
Windows XP, Vista, Windows 7.8, Linux, Mac OS X, Android |
| Sensing Position Correction |
13 point touchscreen calibration |
| Wavelength Detection |
850nm |
| Remote Contol |
Operating distance of the Remote Control |
≤8m ±30° |
| Environmental Parameters |
Operating Temperature Range |
5°C ～ 40°C |
| Operating humidity range |
%10 ～ %85 |
| Storage Temperature Range |
-20°C ～ 55°C |
| Storage humidity range |
%5 ～ %95 |
| Operating and Storage Atmospheric Pressure Range |
86kPa ～ 104kPa |
| Computer Details |
CPU |
RPG 3rd generation Intel ® Core ™ processors (Intel i3 Intel i5 or Intel i7) |
| Graphics |
Intel integrated graphics client HM4000 |
| Memory |
4GB DDR2 1333Mhz (8GB support) |
| Storage |
500GB SATA3 7200rpm drive |
| Operating System Support |
Windows 7 / Windows 8 / XP / WES7 / WES2009 / Linux |
